Heavy-Duty Vibrating Screen
HSX YK/YA Series heavy vibrating screens deliver high-throughput, high-accuracy classification and scalping for abrasive mineral ores, crushed stone, quarry aggregates, and raw coal. Featuring dual eccentric vibration exciters, adjustable vibration amplitude, and a robust side-plate huck-bolted frame, the YK Series withstands continuous severe dynamic loading without fatigue cracking.
Model Series & Engineering Parameters 5 Heavy Mining Models
| Model Series | Deck Size (W x L mm) | Decks | Max Feed Size (mm) | Capacity (t/h) | Motor Power (kW) |
|---|---|---|---|---|---|
| 2YK1548 | 1,500 x 4,800 mm | 2 Decks | 200 mm | 50 – 180 t/h | 15.0 kW |
| 2YK1848 | 1,800 x 4,800 mm | 2 Decks | 250 mm | 80 – 260 t/h | 18.5 kW |
| 2YK2160 | 2,100 x 6,000 mm | 2 Decks | 300 mm | 150 – 420 t/h | 22.0 kW |
| 3YK2460 | 2,400 x 6,000 mm | 3 Decks | 350 mm | 200 – 600 t/h | 30.0 kW |
| 3YK3060+ | 3,000 x 6,000 mm | 3 Decks | 400 mm | 350 – 800 t/h | 37.0 – 45.0 kW |
Ordering Nomenclature Guide: [Decks: 1/2/3] YK - [Width dm][Length dm] - [Media: Polyurethane / Wire Mesh] - [Ex].
Built for Massive Impact and High Screening Accuracy
High-efficiency circular motion provides self-cleaning action and prevents blinding in wet or sticky materials.
Weld-Free Huck-Bolted Frame Construction
Side plates are cold-riveted using heavy-duty Huck lockbolts, completely eliminating thermal weld stress and cyclic fatigue fractures.
Modular Replaceable Screening Media
Compatible with modular polyurethane screen panels, manganese steel woven wire, or punched rubber plate systems.
Self-Aligning Spherical Roller Bearings
Specialized vibration-duty spherical roller bearings with grease labyrinth seals provide over 20,000 hours of continuous service.
Heavy Spiral Steel Spring Isolation
High-fatigue spiral coil springs isolate up to 98% of dynamic vibration from plant structures, ensuring quiet and stable foundation loads.
Proven in Severe Plant Environments
Delivering high thrust and zero-drift actuation across critical heavy industrial facilities.
Mining Primary & Secondary Crushing
Scalping oversized rock boulders prior to cone and jaw crushers, protecting downstream plants.
Coal Preparation & Sizing Plants
Efficient wet and dry coal separation, de-sliming, and graded lump classification.
Aggregate & Quarry Lines
High-precision sizing of construction sand, base gravel, and railway ballast.
Metallurgical Sinter Screening
High-temperature hot sinter and pellet screening under continuous severe blast furnace feed.
Request Technical Quotation & Sizing Proposal
Submit your required parameters, operating duty, or project drawings for Heavy-Duty Vibrating Screen. Our export engineering team will review your specifications and provide an official quotation within 24 hours.
