Self-Controlled Hydraulic Belt Tensioning Device
HSX DYL Series self-controlled hydraulic belt tensioners maintain stable, mathematically controlled take-up tension across heavy conveyor belts under changing startup, running, and heavy-surge load conditions. By eliminating belt sag and drive pulley slippage, the DYL system protects long-distance conveyor belting from fatigue breakdown and catastrophic tears.
Model Series & Engineering Parameters 6 Standard Tension Classes
| Model Series | Rated Tension (kN) | Take-Up Travel (m) | Tensioning Speed (mm/s) | Motor Power (kW) | System Pressure (MPa) |
|---|---|---|---|---|---|
| DYL-40 | 40.0 kN | 1.0 – 3.0 m | 15 – 35 mm/s | 4.0 kW | 16.0 MPa |
| DYL-63 | 63.0 kN | 1.5 – 4.5 m | 15 – 30 mm/s | 5.5 kW | 16.0 MPa |
| DYL-100 | 100.0 kN | 2.0 – 6.0 m | 12 – 25 mm/s | 7.5 kW | 20.0 MPa |
| DYL-160 | 160.0 kN | 2.5 – 8.0 m | 10 – 22 mm/s | 11.0 kW | 21.0 MPa |
| DYL-250 | 250.0 kN | 3.0 – 10.0 m | 8 – 18 mm/s | 18.5 kW | 25.0 MPa |
| DYL-400+ | 400 – 600 kN | Up to 15.0 m | Custom High Speed | 30.0 kW | 28.0 MPa |
Ordering Nomenclature Guide: DYL - [Rated Tension kN] / [Travel Stroke m] - [Drive: Cylinder / Winch] - [Control: Smart PLC] - [Ex].
Engineered for Zero Belt Slip and Surge Absorption
Automatically increases tension by 1.3-1.5x during motor acceleration, then smoothly ramps back to nominal running tension.
Intelligent Multi-Stage Tension Control
Automatically switches between startup tensioning, steady-state cruise tensioning, and emergency brake tensioning via digital PLC.
High-Response Hydraulic Accumulator Banks
Bladder accumulator bank instantly dampens transient shock waves when heavy shock loads drop onto the conveyor belt.
Dynamic Cable Winch & Cylinder Synergy
Combines large hydraulic take-up travel with hydraulic cylinder precision, accommodating thermal expansion and belt stretch.
Fail-Safe Mechanical Locking Dog
High-reliability mechanical lock holds the carriage securely in place during hydraulic maintenance or plant shutdown.
Proven in Severe Plant Environments
Delivering high thrust and zero-drift actuation across critical heavy industrial facilities.
Deep Shaft Mine Inclined Belts
Prevents belt roll-back and slip across steep high-tonnage mining conveyor declines and inclines.
Multi-Kilometer Overland Conveyors
Absorbs complex longitudinal wave oscillations during long-distance conveyor startup and stopping.
Coal Fired Power Plant Feeders
Maintains unyielding tension for main boiler feeding trunk lines under 24/7 continuous duty.
High-Throughput Port Shiploaders
Eliminates take-up tower counterweight jams, saving valuable jetty and dock top structure.
Request Technical Quotation & Sizing Proposal
Submit your required parameters, operating duty, or project drawings for Self-Controlled Hydraulic Belt Tensioning Device. Our export engineering team will review your specifications and provide an official quotation within 24 hours.
